Description
| CODE | 001Y6080A121MOMR | 001Y6100A101MOMR | 001Y6120A081MOMR |
|---|---|---|---|
| Torque (Nm) | 80 | 001E002 | 120 |
| Rpm speed (turns/min) | 12 | 10 MAX | 8 |
| Hoisted weight (Kg)* | 114 | 143 | 171 |
| Limit switch revolutions (revolutions) | 20 | 20 | 20 |
| Duration of operation (min) | 4 | 4 | 4 |
| Protection rating (IP) | 44 | 44 | 44 |
| Absorption (A) | 1,65 | 1,68 | 1,68 |
| Power (W) | 385 | 393 | 393 |
| Length (mm) = L1 | 790 | 790 | 810 |
| Weight (Kg) | 5,2 | 5,2 | 6 |
| Package dimensions (mm) | 860 x 120 x 120 | 860 x 120 x 120 | 860 x 120 x 120 |
| Weight of packed motor (Kg) | 5,6 | 5,74 | 6,6 |
