Description
| CODE | 001Y6080A121MOM | 001Y6100A121MOM | 001Y6120A101MOM |
|---|---|---|---|
| Torque (Nm) | 80 | 001E002 | 120 |
| Rpm speed (turns/min) | 12 | 12 | 10 MAX |
| Hoisted weight (Kg)* | 114 | 143 | 171 |
| Limit switch revolutions (revolutions) | 20 | 20 | 20 |
| Duration of operation (min) | 4 | 4 | 4 |
| Protection rating (IP) | 44 | 44 | 44 |
| Absorption (A) | 1,71 | 1,7 | 1,85 |
| Power (W) | 396 | 393 | 425 |
| Length (mm) = L1 | 610 | 610 | 630 |
| Weight (Kg) | 5,08 | 5,25 | 5,6 |
| Package dimensions (mm) | 685 x 120 x 120 | 685 x 120 x 120 | 750 x 120 x 120 |
| Weight of packed motor (Kg) | 5,48 | 5,65 | 6,6 |
